ECM High-Efficiency Circulator

The 00e® series — VR1816 circulator is an infinitely variable speed, high-efficiency wet rotor circulator with an ECM permanent magnet motor. Operating modes include infinitely variable fixed speed and self-adjusting constant pressure or proportional pressure variable speed.

Features

• 18’ Shut-off head, 16 gpm max flow
• ECM High-efficiency motor
• Easy to use dial to set operating speed or pressure control
• Operates in 3 different modes:

  • Infinitely Variable Fixed Speed
  • Constant Pressure — Self-adjusting, Variable Speed
  • Proportional Pressure — Self-adjusting, Variable Speed
• 5 color LED displays:

  • Operating mode (Blue, Orange or Green)
  • Error code diagnostics (Red or White)
• Use with a Taco ZVC Zone Valve Control or SR Switching Relay for ON/OFF operation
• Integral Flow Check (IFC®) included
• Whisper quiet operation
• An optional 2-way flange reduces SKUs and provides universal fit-up to any flange position
• Double insulated, no ground required

Specifications

• Maximum Shut-off Head:1 8feet
• Maximum Flow:16gpm
• Maximum Operating Pressure:
  • 125psi
  • (8.6 bar)
• Maximum Water Temp: 230°F(110°C)
• Minimum Water Temp: 36°F(2°C)
• Electrical specifications:

  • Voltage: 120V, 60 Hz Single phase
  • Operating Power: 4W - 44W
  • Max. AMP Rating: 0.54
