Features
- High efficiency ECM motor with centrifugal fan
- Quiet blower operation
- Use with any hot water appliance with pressures to 150 PSI
- High efficiency fin tube coils
- Single stage or 2-stage heating and cooling
- Standard thermostat capable
Control for external pump (5A – 120V) - WiFi connection for programming with the IBCconnect mobile app
- Included – sensors for supply air, return air, supply water, return water, humidifier, dehumidifier, and frost protection
- Lead-free coil for pairing with a tankless water heater
- Easy service access
- Standard filter
Specifications
- Max. Water Temperature: 195 °F
- Coil Performance at 180°F(BTU/Hr): 66,800
- Water Pipe Connections: 3/4" MPT
- External Static Pressure (WC) low/med/high: 0.5/1.0/1.5
- Maximum Operating Water Pressure: 150 PSI
- Width: 17.5'
- Depth: 26"
- Height: 32"
- Supply Air Opening Width: 16"
- Supply Air Opening Depth: 19.6"
- Side Return Air Opening Height: 7"
- Side Return Air Opening Depth: 23"
- Bottom Return Air Opening Width: 13"
- Bottom Return Air Opening Depth: 23"
- Max. Internal Current Power Rating 120 Volts: 2.4 Amp
- External Pump Supply 120 Volts: 4 Amp
- Voltage: 120 V
- Max. Air Flow @ 0.5” Rated Static Pressure: 1,134 CFM
- Max. Return Air Temperature: 122 °F
- Filter Size (inches): Not Supplied 16 x 25 x 1
- Weight (Boxed): 98lbs
Downloads
- Brochure
