Penetration Type K Thermocouple
FieldpieceWrite a Review
Fieldpiece
Penetration Type K Thermocouple
The ATR1 type K thermocouple is ideal for measuring the temperature of the air circulating in ducts. The long rod can reach the center of the ducts to precisely measure the air temperature in the entire section. The large handle gives the HVAC technician enough strength to puncture flexible conduit using the pointed tip. The ATR1 can be used with all our temperature measurement multimeters and any thermometer that accepts a type K thermocouple.
- Rod length: 12 cm (4.75 in)
- Rod diameter: 3.2 mm (0.125 in)
- Thermocouple cable length: 1.2 m (4 ft)
- Accuracy:
- ±0.5 °C (-150 to 0°C); ±1°F (-238 to 32°F)±1.5°C (0 to 100°C); ±3°F (32 to 212°F) ±2 (100 to 500°C); ±4°F (212 to 932°F) ±3.2°C (500 to 800°C); ±6°F (932 to 1472°F)
- Temperature Range: -150°C to 800°C (-238°F to 1472°F)Thermocouple Leads: Nickel
- Chromium/Nickel Aluminum Type K
- Plug: Mini - type K thermocouple male plug
